Parameter overview with brief description
100% bargraph value 3
Value 4 display
0% bargraph value 3
Value 3 display
100% bargraph value 1
Value 2 display
Parameter Prerequisite Description User Entry Factory Setting
Format display A local display is
provided.
Select how measured
values are shown on
the display.
•1 value, max.
size
• 1 bargraph +
1 value
•2 values
• 1 value large
+ 2 values
•4 values
1 value, max. size
Value 1 display A local display is
provided.
Select the measured
value that is shown on
the display.
• Concentration
•Dewpoint 1
•Dewpoint 2
•Cell gas
pressure
•Cell gas tem-
perature
Concentration
0% bargraph
value 1
A local display is
provided.
Enter 0% value for bar
graph display
Signed floating-
point number
0 ppmv
100% bargraph
value 1
A local display is
provided.
Enter 100% value for
bar graph display
Signed floating-
point number
Depends on calibration
range
Value 2 display A local display is
provided.
Select the measured
value that is shown on
the local display.
•None
• Concentration
•Dewpoint 1
•Dewpoint 2
•Cell gas
pressure
•Cell gas tem-
perature
Dewpoint 1
