Endress+Hauser SpectraSensors J22 TDLAS User Manual

J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 87
Parameter overview with brief description
Output values for switch output
The switch output 1 to n submenu contains all the parameters needed to display
the current measured values for every switch output.
Navigation
"Diagnostics" menu → Measured values → Output values → Switch output 1 to n
Parameter overview with brief description
Output values for relay output
The Relay output 1 to n submenu contains all the parameters needed to display
the current measured values for every relay output.
Navigation
"Diagnostics" menu → Measured values → Output values → Relay output 1 to n
Parameter Description User Interface
Output current 1 Displays the current value currently calcu-
lated for the current output.
3.59 to 22.5 mA
Measured current Displays the current value currently mea-
sured for the current output.
0 to 30 mA
Switch status 1 to n
Switch output 1 to n
Parameter Prerequisite Description
User Interface/
User Entry
Factory Setting
Switch status 1
to n
The Switch option
is selected in the
Operating mode
parameter.
Displays the current
switch output status.
•Open
•Closed
—
Switch status
Relay output 1 to n
Switch cycles
Max. switch cycles number
