4900002277 J22 TDLAS Gas Analyzer
2 SpectraSensors, Inc.
Tools symbols
Standard
Documentation
All documentation is available:
• On the USB provided with the analyzer
• SpectraSensors’ website: www.spectrasensors.com
Each analyzer shipped from the factory is packaged with documents specific to the
model that was purchased. This document is an integral part of the complete
document package, which also includes:
LED
Light emitting diode is flashing.
Symbol Description Symbol Description
T20 Torx screwdriver Flat blade screwdriver
Open-ended wrench Phillips screwdriver
Tape measure Hex driver
Felt-tip marking pen Level
Symbol Description
Part Number Document Type Description
4900002275 Safety Manual Requirements for installing or operat-
ing the J22 TDLAS Gas Analyzer related
to personnel or equipment safety.
4900002276 Brief Operating
Instruction
A quick guide to specialists for installing
the device.
•Installation
• Commissioning
4900002278 Device Parameters
Description
Provides a detailed explanation for each
parameter and Modbus-specific infor-
mation in the Expert operating menu.
This document is intended for personnel
working with the device over the entire
life cycle to perform specific tasks.
