Endress+Hauser SpectraSensors J22 TDLAS - Configuring the Current Output

J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 95
Parameter overview with brief description
Configuring the current output
The Current output wizard guides you systematically through all the parameters
that have to be set for configuring the current output.
I/O module 1 to n terminal numbers
Communication
I/O module 1 to n information
I/O module 1 to n type
Apply I/O configuration
Conversion code
Parameter Description User Entry Factory Setting
I/O module 1 to n ter-
minal numbers
Shows the terminal numbers used
by the I/O module.
•Not used
• 26-27 (I/O 1)
• 24-25 (I/O 2)
1)
• 22-23 (I/O 3)
1)
-
I/O module 1 to n infor-
mation
Shows information of the plugged
I/O module.
• Not plugged
•Invalid
•Not configurable
• Configurable
-
I/O module 1 to n type Shows the I/O module type. • Off
•Current output
2)
•Switch output
2)
-
Apply I/O configuration Apply parameterization of the
freely configurable I/O module.
•No
•Yes
No
Conversion code Enter the code to change the I/O
configuration.
Positive integer 0
1) Based on order configuration.
2) Visibility depends on order options or device settings.
