J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 29
-: Warning
• : Locking (the device is locked via the hardware )
• : Communication (communication via remote operation is active)
Display area
In the display area, each measured value is prefaced by certain symbol types for
further description:
Measured values
Diagnostic behavior
The number and display format of the measured values can be configured via
the "Format display" parameter → 66.
Measured variable
Measurement channel
number
Diagnostic behavior
Example:
Appears only if a diagnostics
event is present for this
measured variable.
Symbol Meaning
•Temperature
• Dew point temperature
Output
The measurement channel number indicates which of the
outputs is displayed.
Concentration
p
Pressure
The diagnostic behavior pertains to a diagnostic event that is relevant to the displayed measured variable.
For information on the symbols → 136
