J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 65
Configuring the relay output
The Relay output wizard guides the user systematically through all the
parameters that have to be set for configuring the relay output.
Navigation
"Setup" menu → Relay output 1 to n
Parameter overview with brief description
Relay output function
Relay output 1 to n
Assign limit
Assign diagnostic behavior
Assign status
Switch-off value
Switch-on value
Failure mode
Terminal number
Switch-off delay
Switch-on delay
Parameter Prerequisite Description User Entry Factory Setting
Relay output
function
— Select the function for
the relay output.
•Closed
•Open
• Diagnostic
behavior
•Limit
Diagnostic behavior
Terminal number — Shows the terminal
numbers used by the
relay output module.
•Not used
• 24-25 (I/O 2)
• 22-23 (I/O 3)
—
Assign limit In the Relay output
function parameter,
the Limit option is
selected.
Select process variable
for limit function.
Concentration Off
