4900002277 J22 TDLAS Gas Analyzer
44 SpectraSensors, Inc.
If a login page does not appear, or if the page is incomplete → 110.
Logging on
1. Select the preferred operating language for the Web browser.
2. Enter the user-specific access code.
3. Press OK to confirm your entry.
If no action is performed for 10 minutes, the Web browser automatically
returns to the login page.
User interface
A0029418-SSI
1 Function row
2 Operating language
3 Navigation area
Header
The following information appears in the header:
•Device tag
• Device status with status signal → 138
• Current measured values
Function row
Access code
0000 (factory setting); can be changed by customer
Functions Meaning
Measured values Displays the measured values of the measuring device.
Menu • Access to the operating menu from the measuring device
• The structure of the operating menu is the same as for the
local display
Device status Displays the diagnostic messages currently pending, listed in
order of priority.
Concentration
Cal select
Cell gas pressure
Cell gas temperature
42.4773
ppmv
1
0.9566
bar
13.2818
