4900002277 J22 TDLAS Gas Analyzer
98 SpectraSensors, Inc.
Navigation
"Setup" menu → switch output
Parameter overview with brief description
Operating mode
Switch output 1 to n
Terminal number
Signal mode
Switch output function
Assign diagnostic behavior
Assign status
Assign limit
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Invert output signal
Parameter Prerequisite Description User Entry Factory Setting
Operating mode — Define the output as a
switch output.
Switch Switch
Terminal number — Shows the terminal
numbers used by the
S output module.
•Not used
• 24-25 (I/O 2)
• 22-23 (I/O 3)
—
Signal mode — Select the signal mode
for the S output.
• Passive
•Active
Passive
