Physical Specifications
Weight J22 TDLAS Gas Analyzer: 16 kg (36 lbs)
J22 TDLAS Gas Analyzer with SCS
1
on Panel: 24 kg
(53 lbs)
J22 TDLAS Gas Analyzer with Enclosed SCS
1
/
J22 TDLAS Gas Analyzer with Enclosed SCS
1
, Heated:
43 kg (95 lbs)
Dimensions J22 TDLAS Gas Analyzer
CSA: 727 mm H x 236.2 mm D x 224 mm W
(28.6 in. H x 9.3 in. D x 8.8 in. W)
ATEX: 727 mm H x 236.2 mm D x 192 mm W
(28.6 in. H x 9.3 in. D x 7.5 in. W)
J22 TDLAS Gas Analyzer with SCS
1
on Panel
737 mm H x 241 mm D x 376 mm W
(29 in. H x 9.5 in. D x 14.8 in. W)
J22 TDLAS Gas Analyzer with Enclosed SCS
1
/
J22 TDLAS Gas Analyzer with Enclosed SCS
1
, Heated
838 mm H x 255 mm D x 406 mm W
(33 in. H x 10 in. D x 16 in. W)
Area Classification
J22 TDLAS Gas Analyzer cCSAus: Ex db ia op is IIC T4 Gb
Class I, Zone 1, AEx db ia op is IIC T4 Gb
Class I, Division 1, Groups A, B, C, D, T4
Tambient = -20 C to +60 C
ATEX/IECEx
: II 2G
Ex db ib op is IIC T4 Gb
Tambient = -20 C to +60 C
J22 TDLAS Gas Analy-
zer with SCS
1
on Panel
cCSAus
: Ex db ia op is IIC T4 Gb
Class I, Zone 1, AEx db ia op is IIC T4 Gb
Class I, Division 1, Groups A, B, C, D, T4
Tambient = -20 C to +60 C
ATEX/IECEx
: II 2G
Ex db ib op is h IIC T4 Gb
Tambient = -20 C to +60 C
J22 TDLAS Gas Ana-
lyzer with Enclosed SCS
1
cCSAus: Ex db ia op is IIC T4 Gb
Class I, Zone 1, AEx db ia op is IIC T4 Gb
Class I, Division 1, Groups A, B, C, D, T4
Tambient = -20 C to +60 C
ATEX/IECEx
: II 2G
Ex db ib op is h IIC T4 Gb
Tambient = -20 C to +60 C
1 Sample Conditioning System
