Event Log Summary (continued)
EVENT
LOG
ASCII
Log
Code
ASCII
Event
Code
PSN Id
Rec.
Ver.
Dev.
Type
Even
t
No.
Event
Name
Even
t
Flags
(1)
Show
Seq.
No.
Time
Stamp
Down
Time
(2)
Sync
Loop
Prog.
No.
Show
Statu
s
(3)
Cue
No.
Event Specific
Parameters
Clock set from CAI
Channel 1
LOG, EVT, 0, 1-63, 0, 12, 80, ClkCAI1, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Clock set from CAI
Channel 2
LOG, EVT, 0, 1-63, 0, 12, 81, ClkCAI2, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Clock set from CAI
Channel 3
LOG, EVT, 0, 1-63, 0, 12, 82, ClkCAI3, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Event Log Buffer
cleared from CAI
Channel 1
LOG, EVT, 0, 1-63, 0, 12, 83, ClrBufC1, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Event Log Buffer
cleared from CAI
Channel 2
LOG, EVT, 0, 1-63, 0, 12, 84, ClrBufC2, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Event Log Buffer
cleared from CAI
Channel 3
LOG, EVT, 0, 1-63, 0, 12, 85, ClrBufC3, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Show Sequence
Number Cleared
from CAI Channel 1
LOG, EVT, 0, 1-63, 0, 12, 86, ClrSSQC1, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Show Sequence
Number Cleared
from CAI Channel 1
LOG, EVT, 0, 1-63, 0, 12, 87, ClrSSQC2, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Show Sequence
Number Cleared
from CAI Channel 1
LOG, EVT, 0, 1-63, 0, 12, 88, ClrSSQC3, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
NTP Server time out LOG, EVT, 0, 1-63, 0, 12, 89, ClkNTPTO, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Digital Input Abort LOG, EVT, 0, 1-63, 0, 12, 90, InpAbort d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Channel 1 Exception
Timer time out
LOG, EVT, 0, 1-63, 0, 12, 91, CueXTO_1, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Channel 2 Exception
Timer time out
LOG, EVT, 0, 1-63, 0, 12, 92, CueXTO_2, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Channel 3 Exception
Timer time out
LOG, EVT, 0, 1-63, 0, 12, 93, CueXTO_3, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Macro Memory Fault LOG, EVT, 0, 1-63, 0, 12, 94, MemMacro, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Macro Call LOG, EVT, 0, 1-63, 0, 12, 95, Macxxayy, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,p3,p4,p5,p6,p7,0,
SENDF1
Event Report
LOG, EVT, 0, 1-63, 0, 12, 96, SENDF1, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF2
Event Report
LOG, EVT, 0, 1-63, 0, 12, 97, SENDF2, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF3
Event Report
LOG, EVT, 0, 1-63, 0, 12, 98, SENDF3, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF4
Event Report
LOG, EVT, 0, 1-63, 0, 12, 99, SENDF4, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF5
Event Report
LOG, EVT, 0, 1-63, 0, 12, 100, SENDF5, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF6
Event Report
LOG, EVT, 0, 1-63, 0, 12, 101, SENDF6, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF7
Event Report
LOG, EVT, 0, 1-63, 0, 12, 102, SENDF7, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF8
Event Report
LOG, EVT, 0, 1-63, 0, 12, 103, SENDF8, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Macro Exited due to
Exit If Instruction
LOG, EVT, 0, 1-63, 0, 12, 104, Xifmm_nn, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Line Voltage Hi/Lo LOG, EVT, 0, 1-63, 0, 12, 105, VoltHiLo d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
SENDF9
Event Report
LOG, EVT, 0, 1-63, 0, 12, 106, SENDF9, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF10
Event Report
LOG, EVT, 0, 1-63, 0, 12, 107, SENDF10, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF11
Event Report
LOG, EVT, 0, 1-63, 0, 12, 108, SENDF11, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF12
Event Report
LOG, EVT, 0, 1-63, 0, 12, 109, SENDF12, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF13
Event Report
LOG, EVT, 0, 1-63, 0, 12, 110, SENDF13, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF14
Event Report
LOG, EVT, 0, 1-63, 0, 12, 111, SENDF14, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF15
Event Report
LOG, EVT, 0, 1-63, 0, 12, 112, SENDF15, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF16
Event Report
LOG, EVT, 0, 1-63, 0, 12, 113, SENDF16, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF17
Event Report
LOG, EVT, 0, 1-63, 0, 12, 114, SENDF17, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF18
Event Report
LOG, EVT, 0, 1-63, 0, 12, 115, SENDF18, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF19
Event Report
LOG, EVT, 0, 1-63, 0, 12, 116, SENDF19, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF20
Event Report
LOG, EVT, 0, 1-63, 0, 12, 117, SENDF20, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF21
Event Report
LOG, EVT, 0, 1-63, 0, 12, 118, SENDF21, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
