Event Log Summary (continued)
EVENT
LOG
ASCII
Log
Code
ASCII
Event
Code
PSN Id
Rec.
Ver.
Dev.
Type
Even
t
No.
Event
Name
Even
t
Flags
(1)
Show
Seq.
No.
Time
Stamp
Down
Time
(2)
Sync
Loop
Prog.
No.
Show
Statu
s
(3)
Cue
No.
Event Specific
Parameters
SENDF22
Event Report
LOG, EVT, 0, 1-63, 0, 12, 120, SENDF23, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF23
Event Report
LOG, EVT, 0, 1-63, 0, 12, 120, SENDF23, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF24
Event Report
LOG, EVT, 0, 1-63, 0, 12, 121, SENDF24, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF25
Event Report
LOG, EVT, 0, 1-63, 0, 12, 122, SENDF25, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF26
Event Report
LOG, EVT, 0, 1-63, 0, 12, 123, SENDF26, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF27
Event Report
LOG, EVT, 0, 1-63, 0, 12, 124, SENDF27, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF28
Event Report
LOG, EVT, 0, 1-63, 0, 12, 125, SENDF28, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF29
Event Report
LOG, EVT, 0, 1-63, 0, 12, 126, SENDF29, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
SENDF30
Event Report
LOG, EVT, 0, 1-63, 0, 12, 127, SENDF30, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Macro Call Level
Limit Error
LOG, EVT, 0, 1-63, 0, 12, 128, MacLimit, d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,p3,p4,p5,p6,p7,0,
Control Event
Program Start
Instruction
LOG, EVT, 0, 1-63, 0, 12, 129, Start_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event
Program Stop
Instruction
LOG, EVT, 0, 1-63, 0, 12, 130, Stop_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event
Program Resume
Instruction
LOG, EVT, 0, 1-63, 0, 12, 131, Resume_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event
Major Fault
Instruction
LOG, EVT, 0, 1-63, 0, 12, 132, Fault_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Command Limit
Exceeded
LOG, EVT, 0, 1-63, 0, 12, 133, CmdLimit d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Task at Reset LOG, EVT, 0, 1-63, 0, 12, 134 ResetTsk d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,p3,p4,0,0,0,0,
Remote Device
Execute Button
LOG, EVT, 0, 1-63, 0, 12, 135 Button d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,p3,0,0,0,0,0,
Control Event Reboot
eCNA Instruction
LOG, EVT, 0, 1-63, 0, 12, 136 RBoot_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event
Program Cue
Instruction
LOG, EVT, 0, 1-63, 0, 12, 137 Cue_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event
Program Abort
Instruction
LOG, EVT, 0, 1-63, 0, 12, 138 Abort_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Control Event Set
Program Instruction
LOG, EVT, 0, 1-63, 0, 12, 139 SProg_CE d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, p1,p2,0,0,0,0,0,0,
Fault from CAI
Channel 4
LOG, EVT, 0, 1-63, 0, 12, 141 CAI4Flt d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Stop from CAI
Channel 4
LOG, EVT, 0, 1-63, 0, 12, 142 StopCAI4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Start from CAI
Channel 4
LOG, EVT, 0, 1-63, 0, 12, 143 StrtCAI4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Program Abort from
CAI Channel 4
LOG, EVT, 0, 1-63, 0, 12, 144 AbtCAI4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Event Log Buffer
cleared from CAI
Channel 4
LOG, EVT, 0, 1-63, 0, 12, 145 ClrBufC4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Show Sequence
Number Cleared
from CAI Channel 4
LOG, EVT, 0, 1-63, 0, 12, 146 ClrSSQC4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Clock was set from
CAI Channel 4
LOG, EVT, 0, 1-63, 0, 12, 147 ClkCAI4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Program Cue from
CAI Channel 4
LOG, EVT, 0, 1-63, 0, 12, 148 CueCAI4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Channel 4 Exception
Timer time out
LOG, EVT, 0, 1-63, 0, 12, 149 CueXTO_4 d, 0-999, yyyy,mm,dd,hh,mm,ss,ttt, d, 0, 0-9, d, 0-20, 0,0,0,0,0,0,0,0,
Note 1: Event Flags. d = 32 bit decimal number. See Event Flags on next page.
Note 2: Down Time. d = 2 byte decimal number which equals the total number of seconds a program has been stopped.
Note 3: Show Status. d = 1 byte decimal number. 1 = Ready to Run, 2 = Fault, 3 = Running, 4 = Intermission, 5 = Stopped
