House Lights Output Instructions

These instructions control the House Lights output flags and will operate relays assigned to these

flags for one of five states: Up, Down, Mid 1, Mid 2 and None. This instruction also activates light

states on the QDC-400 dimmer control board.

The House Lights offset timer (dd:dd) can be used to delay the execution of the output.

House Lights Up dd:dd Sets the House Lights Up flag. Clears the Mid 1, Mid 2 and Down flags

House Lights Mid 1 dd:dd Sets the House Lights Mid 1 flag. Clears the Up, Mid 2 and Down flags

House Lights Mid 2 dd:dd Sets the House Lights Mid 2 flag. Clears the Up, Mid 1 and Down flags

House Lights Down dd:dd Sets the House Lights Down flag. Clears the Up, Mid 1 and Mid 2 flags

House Lights None dd:dd Clears the Up, Mid 1, Mid 2 and Down flags

dd:dd = 0:00 to 59:59 (minutes:seconds)

Stage Lights Output Instructions

These instructions control the Stage Lights output flags and will operate relays assigned to these

flags for one of three states: Up, Down and None. This instruction also activates light states on the

QDC-400 dimmer control board.

The Stage Lights offset timer (dd:dd) can be used to delay the operation of the output.

Stage Lights Up dd:dd Sets the Stage Lights Up flag. Clears the Mid 1, Mid 2 and Down flags

Stage Lights Down dd:dd Sets the Stage Lights Down flag. Clears the Up, Mid 1 and Mid 2 flags

Stage Lights None dd:dd Clears the Up, Mid 1, Mid 2 and Down flags

dd:dd = 0:00 to 59:59 (minutes:seconds)

Curtain Output Instructions

These instructions control the Curtain output flags and will operate relays assigned to these flags for

one of three states: Open, Close and None.

The Curtain offset timer (dd:dd) can be used to delay the operation of the output.

Curtain Open dd:dd Sets the open flag; clears the close flag

Curtain Close dd:dd Sets the close flag; clears the open flag

Curtain None dd:dd Clears both the open and close flags

dd:dd = 0:00 to 59:59 (minutes:seconds)

Slide Projector Output Instructions

This instruction controls the Slide Projector output control flag and will operate any relay assigned

to this flag.

The Slide Projector offset timer (dd:dd) can be used to delay the operation of the output control flag.
