The Sound offset timer (dd:dd) can be used to delay the operation of the output control flag.
Sound: Non-Sync dd:dd Sets the Non-Sync flag. Clears all other sound flags
Sound: Mono dd:dd Sets the Mono flag. Clears all other sound flags
Sound: SVA dd:dd Sets the SVA flag. Clears all other sound flags
Sound: SR dd:dd Sets the SR flag. Clears all other sound flags
Sound: Digital 1 dd:dd Sets the Digital 1 flag. Clears all other sound flags
Sound: Aux 1 dd:dd Sets the Aux 1 flag. Clears all other sound flags
Sound: Digital 2 dd:dd Sets the Digital 2 flag. Clears all other sound flags
Sound: Aux 2 dd:dd Sets the Aux 2 flag. Clears all other sound flags
Sound: Mute On dd:dd Sets the Mute flag and memorizes the previous sound state
Sound: Mute Off dd:dd Clears the Mute flag and restores the previous sound state
Sound: None dd:dd Clears all sounds flags
dd:dd = 0:00 to 59:59 (minutes:seconds)
When using this instruction, be aware of the following rules:
• A Sound Mute On instruction will turn off any other sound output.
• A Sound Mute Off instruction will cause the previous sound output to be restored.
• Executing a new sound instruction, including Sound None, will not turn off the mute output. Only
a Sound Mute Off instruction will turn off mute.
• When mute is on, a Sound Mute On instruction will not cause the mute output to re-pulse.
Masking Output Instruction
This instruction controls the three Masking output control flags and will operate relays assigned to
these flags to any one of four states: Flat, Scope, Special and None. This instruction is normally
used to control the screen masking curtains.
The Masking offset timer (dd:dd) can be used to delay the operation of the output control flag.
Masking: Flat dd:dd Sets the Flat flag. Clears the Scope and Special flags
Masking: Scope dd:dd Sets the Scope flag. Clears the Flat and Special flags
Masking: Special dd:dd Sets the Special flag. Clears the Flat and Scope flags
Masking: None dd:dd Clears the Flat, Scope and Special flags
dd:dd = 0:00 to 59:59 (minutes:seconds)
Lens Output Instruction
This instruction controls the three Lens output control flags and will operate relays assigned to these
flags to any one of four states: Flat, Scope, Special and None. This instruction is normally used to
control the projector lens turet.
The Lens offset timer (dd:dd) can be used to delay the operation of the output control flag.
Lens: Flat dd:dd Sets the Flat flag. Clears the Scope and Special flags
Lens: Scope dd:dd Sets the Scope flag. Clears the Flat and Special flags
Lens: Special dd:dd Sets the Special flag. Clears the Flat and Scope flags
Lens: None dd:dd Clears the Flat, Scope and Special flags
dd:dd = 0:00 to 59:59 (minutes:seconds)
Lens/Masking Output Instruction
This instruction controls the Lens and Masking output control flags and will operate relays assigned
to these flags to any one of four states: Flat, Scope, Special and None.
64
eCNA-10 Operation and Installation Manual Version 1.270-00
