Note the Local Alarm can also be silenced by the System Parameters “Local Alarm Time”, Cancel Key,
Cancel Input or CAI “CMD,EVT,0,CNL” command.
Light Level Instruction
This instruction allows control of the light level any preset and fade-in time. This instruction only
works with EPRAD QDC dimmer control boards.
Light Level: m1 m2 m3 m4 dd:dd
m1 = Zone (House, Stage, Zone 3, Zone 4,..., Zone 16)
m2 = Preset (Up, Down, Mid1, Mid2, None, No-op)
m3 = Light Level Offset % (-100% to +100%)
m4 = Fade-in Seconds (“ ”, 0 Sec, 1 Sec, 2 Sec,..., 99 Sec)
dd:dd = 0:00 to 99:99 (minutes:seconds)
The Light Level Offset value, m3 is applied to the selected zone’s level as configured in the “Setup:
QDC-400 Dimmers” setup screen. This is only an override and does not change the configured preset
values.
Note: An offset is used instead of an absolute value because the dimmer allows channels belonging
to the same zone to be configured for different levels.
Wake-On-LAN Instruction
This instruction will broadcast the WoL magic packet to power up a network device.
Wake-On-LAN: m1 m2 dd:dd
m1 = Device name
m2 = Tmr1 - Tmr15 (timer number)
dd:dd = 0:00 to 99:99 (minutes:seconds)
The eCNA must first be configured for the network device’s MAC address from the Wake-ON-LAN
setup screen before using this command.
Control Event Instruction
This instruction can be used to initiate an eCNA event. Only macros support this instruction.
Control Event: m1 m2 dd:dd
m1 = Event
m2 = Tmr1 - Tmr15 (timer number)
dd:dd = 0:00 to 99:99 (minutes:seconds)
Event Description
Start Start Program
Resume Resume Program
Stop Stop Program
Fault Set Set the “CE Fault”
Fault Clear Clear the “CE Fault”
Cue Cue a Program
Abort Abort a Program
Set Program 1 - 9 Set the Program number
Reboot eCNA Reboot the eCNA
72
eCNA-10 Operation and Installation Manual Version 1.270-00
