44
Pa
per Hand
ling
Output tray
The output
tray is
located on t
he top of th
e printer. Si
nce printou
ts
are output face-
down, this tray is al
so referred to as the face-
down
tray. Thi
s tray c
an hold up to 50
0 sheets.
Note:
When you output the large size paper such as A3,
raise the stopper to
prevent your printouts from slipping off the printer.
43
45
