Art-Net Channel Definitions
206
Art-Net is an Ethernet communication protocol based on the TCP/IP
protocol. You can control the projector by using a DMX controller or an
application system (EB‑755F/EB‑750F).
The following table lists the channel definitions used to control the projector
in Art-Net.
Channel/Functi
on
Operation Parameters Default
value
Description
1 Adjusting
light (dimming)
0% to 100% 0 to 255 0 Adjusts the image
brightness.
2 Shutter
control
Shutter open 0 to 63 128 Enables/disables
A/V Mute.
Non-operational 64 to 191
Shutter closed 192 to 255
3 Switch source Non-operational 0 to 7 0 Switches to the
specified source.
HDMI1 8 to 15
HDMI2 16 to 23
HDMI3 24 to 31
Non-operational
(DVI-D)
32 to 39
Non-operational
(Display Port)
40 to 47
Non-operational
(SDI)
48 to 55
Computer1 56 to 63
Computer2 64 to 71
Non-operational
(BNC)
72 to 79
LAN 80 to 87
Screen Mirroring1 88 to 95
Screen Mirroring2 96 to 103
USB Display 104 to 111
Channel/Functi
on
Operation Parameters Default
value
Description
USB 112 to 119
Non-operational
(Spotlight)
120 to 127
Video 128 to 135
Non-operational 136 to 143
Non-operational 144 to 255
7 Zoom Electronic
Tele/Wide
0 to 255 255 Zooms using the
specified amount
of movement.
10 Content
playback
Non-operational 0 to 3 0 Plays the
specified playlist.
Playlist 1 4 to 7
Playlist 2 8 to 11
Playlist 3 12 to 15
Playlist 4 16 to 19
Playlist 5 20 to 23
Playlist 6 24 to 27
Playlist 7 28 to 31
Playlist 8 32 to 35
Playlist 9 36 to 39
Playlist 10 40 to 43
Playlist 11 44 to 47
Playlist 12 48 to 51
Playlist 13 52 to 55
Playlist 14 56 to 59
Playlist 15 60 to 63
Playlist 16 64 to 67
Playlist 17 68 to 71
To Next Page
