Epson TM-T90 - ESC ∗ M Nl Nh D1

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
85 84
TM-T90
Specification
(STANDARD)
ESC ∗
∗∗
∗ m n
L
n
H
d1...dk
[Name] Select bit image mode
[Format] ASCII ESC ∗ m n
L
n
H
d1...dk
Hex 1B 2A m n
L
n
H
d1...dk
Decimal 27 42 m n
L
n
H
d1...dk
[Range] m = 0, 1, 32, 33
1 ≤ (n
L
+ n
H
× 256) ≤ 1023 (0 ≤ n
L
≤ 255, 0 ≤ n
H
≤ 3)
0 ≤ d ≤ 255
[Description] • Specifies the bit image in m mode for the number of dots specified by n
L
and n
H
.
<For ANK/Multilingual model>
m Mode
Number of
dots in
vertical
direction
Vertical dot
density
Horizontal dot
density
Number of bytes (k)
0
8-dot
single-density
8 60 dpi 90 dpi
(n
L
+ n
H
× 256)
1
8-dot
double-density
8 60 dpi 180 dpi
(n
L
+ n
H
× 256)
32
24-dot
single-density
24 180 dpi 90 dpi
(n
L
+ n
H
× 256) × 3
33
24-dot
double-density
24 180 dpi 180 dpi
(n
L
+ n
H
× 256) × 3
dpi: dots per 25.4 mm {1"}
<For Japanese model>
m Mode
Number of
dots in
vertical
direction
Vertical dot
density
Horizontal dot
density
Number of bytes (k)
0
8-dot
single-density
8 203/3 dpi 203/2 dpi
(n
L
+ n
H
× 256)
1
8-dot
double-density
8 203/3 dpi 203 dpi
(n
L
+ n
H
× 256)
32
24-dot
single-density
24 203 dpi 203/2 dpi
(n
L
+ n
H
× 256) × 3
33
24-dot
double-density
24 203 dpi 203 dpi
(n
L
+ n
H
× 256) × 3
dpi: dots per 25.4 mm {1"}
