6.3 Control Commands
HT
[Name] Horizontal tab
[Format] ASCII HT
Hex 09
Decimal 9
[Description] • Moves the print position to the next horizontal tab position.
LF
[Name] Print and line feed
[Format] ASCII LF
Hex 0A
Decimal 10
[Description] • In standard mode
•
Prints the data in the print buffer and feeds one line based on the current line spacing.
• In page mode
•
Moves the print position in memory to feed one line based on the current line spacing.
FF
[Name] Print and return to standard mode (in page mode)
[Format] ASCII FF
Hex 0C
Decimal 12
[Description] • In page mode, prints the data in the print buffer collectively and returns to standard mode.
