DLE EOT n
[Name] Transmit real-time status
[Format] ASCII DLE EOT n
Hex 10 04 n
Decimal 16 4 n
[Range] 1 ≤ n ≤ 4
[Description] • Transmits the status specified by n in real time as follows:
n Function
1 Transmits printer status.
2 Transmits offline status.
3 Transmits error status.
4 Transmits paper roll sensor status
• This printer transmits the following status in real time.
•
n = 1: Printer status
Bit Off/On Hex Decimal Function
0 Off 00 0 Fixed.
1 On 02 2 Fixed.
2 Off 00 0 Drawer kick-out connector pin 3 is LOW.
On 04 4 Drawer kick-out connector pin 3 is HIGH.
3 Off 00 0 Online.
On 08 8 Offline.
4 On 10 16 Fixed.
5 Off 00 0 Not in online waiting status.
On 20 32 During online waiting status.
6 Off 00 0 Paper FEED button is turned Off.
On 40 64 Paper FEED button is turned On.
7 Off 00 0 Fixed.
