Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
185 184
TM-T90
Specification
(STANDARD)
FS q n [x
L
x
H
y
L
y
H
d1...dk]1...[x
L
x
H
y
L
y
H
d1...dk]n
[obsolete command]
GS ( L
<Function 67>, which is the upward-compatible command replacing
FS q
, is recommended for
use, since
FS q
is an obsolete command in the ESC/POS
®
command system.
[Name] Define NV bit image
[Format] ASCII FS q n [x
L
x
H
y
L
y
H
d1...dk]1... [x
L
x
H
y
L
y
H
d1...dk]n
Hex 1C 71 n [x
L
x
H
y
L
y
H
d1...dk]1... [x
L
x
H
y
L
y
H
d1...dk]n
Decimal 28 113 n [x
L
x
H
y
L
y
H
d1...dk]1... [x
L
x
H
y
L
y
H
d1...dk]n
[Range] 1 ≤ n ≤ 255
1 ≤ (x
L
+ x
H
× 256) ≤ 1023 (0 ≤ x
L
≤ 255, 0 ≤ x
H
≤ 3)
1 ≤ (y
L
+ y
H
× 256) ≤ 288 (0 ≤ y
L
≤ 255, y
H
= 0, 1)
0 ≤ d ≤ 255
k = (x
L
+ x
H
× 256) × (y
L
+ y
H
× 256) × 8
Either one of the total capacity data [0, 64K, 128K, 192K, 256K, 320K, 384K] bytes can be
selected by
GS ( E
. The default value is 384 KB.
[Description] • Defines the specified NV bit image.
•
n specifies the number of the NV bit image you are defining.
•
x
L
, x
H
specify the number of dots in the horizontal direction for the NV bit image with [(x
L
+ x
H
× 256) × 8].
•
y
L
, y
H
specify the number of dots in the vertical direction for the NV bit image with [(y
L
+ y
H
× 256) × 8].
• If this command is processed when NV graphics are defined with
GS ( L
or
GS 8 L
, deletes
all NV graphics data, then defines the bit image data with this command.
[Notes] • Frequent write command executions by this command may damage to the NV memory.
Therefore, it is recommended to write to the NV memory 10 times or less a day.
• During processing of this command, the printer is BUSY while writing the data to the NV bit
image memory and stops receiving data. Therefore, it is prohibited to transmit data,
including real-time commands, during the execution of this command.
