Epson TM-T90 Specification

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
92 91
TM-T90
Specification
(STANDARD)
ESC T n
[Name] Select print direction in page mode
[Format] ASCII ESC T n
Hex 1B 54 n
Decimal 27 84 n
[Range] 0 ≤ n ≤ 3, 48 ≤ n ≤ 51
[Default] n = 0
[Description] • Selects the print direction and starting position in page mode.
n Print direction Starting position
0, 48 Left to right Upper left
1, 49 Bottom to top Lower left
2, 50 Right to left Lower right
3, 51 Top to bottom Upper right
ESC V n
[Name] Turn 90° clockwise rotation mode on/off
[Format] ASCII ESC V n
Hex 1B 56 n
Decimal 27 86 n
[Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50
[Default] n = 0
[Description] • Turns 90° clockwise rotation mode on/off in standard mode.
•
When the roll paper is selected:
n Function
0, 48 Turns off 90° clockwise rotation mode
1, 49
2, 50
Turns on 90° clockwise rotation mode

Epson TM-T90 Specifications

General

Brand	Epson
Model	TM-T90
Category	Printer
Language	English
