Epson TM-T90 - Function 112> GS ( L Pl Ph M Fn a Bx by C Xl Xh Yl Yh D1

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
148 147
TM-T90
Specification
(STANDARD)
<Function 112> GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk (fn = 112)
[Format] ASCII GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk
Hex 1D 28 4C pL pH m fn a bx by c xL xH yL yH d1...dk
Decimal 29 40 76 pL pH m fn a bx by c xL xH yL yH d1...dk
[Range]
GS ( L
parameters
11 ≤ (p
L
+ p
H
× 256) ≤ 65535 (0 ≤ p
L
≤ 255, 0 ≤ p
H
≤ 255)
GS 8 L
parameters
11 ≤ (p1 + p2 × 256 + p3 × 65536 + p4 × 16777216) ≤ 4294967295
(0 ≤ p1 ≤ 255, 0 ≤ p2 ≤ 255, 0 ≤ p3 ≤ 255, 0 ≤ p4 ≤ 255)
Common parameters for
GS ( L
/
GS 8 L
m
= 48
fn
= 112
a
= 48
bx
= 1, 2
by
= 1, 2
c
= 49 (when the single-color paper is selected)
c = 49, 50 (when the two-color paper is selected)
1 ≤ (x
L
+ x
H
× 256) ≤ 1024 (0 ≤ x
L
≤ 255, 0 ≤ x
H
≤ 4)
For ANK/Multilingual model:
When single-color paper is specified:
1 ≤ (y
L
+ y
H
× 256) ≤ 1662 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 6) (when by = 1)
1 ≤ (y
L
+ y
H
× 256) ≤ 831 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 3) (when by = 2)
When two-color paper is specified:
1 ≤ (y
L
+ y
H
× 256) ≤ 831 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 3) (when by = 1)
1 ≤ (y
L
+ y
H
× 256) ≤ 415 (0 ≤ y
L
≤ 255, y
H
= 0, 1) (when by = 2)
For Japanese model:
When single-color paper is specified:
1 ≤ (y
L
+ y
H
× 256) ≤ 1476 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 5) (when by = 1)
1 ≤ (y
L
+ y
H
× 256) ≤ 738 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 2) (when by = 2)
When two-color paper is specified:
1 ≤ (y
L
+ y
H
× 256) ≤ 738 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 2) (when by = 1)
1 ≤ (
y
L
+
y
H
× 256) ≤ 369 (0 ≤
y
L
≤ 255,
y
H
= 0, 1) (when
by
= 2)
0 ≤ d ≤ 255
k
= (int ((
x
L
+
x
H
× 256) + 7) / 8) ×(
y
L
+
y
H
× 256)
