TM-T90
Specification
(STANDARD)
GS b n
[Name] Turns smoothing mode on/off
[Format] ASCII GS b n
Hex 1D 62 n
Decimal 29 98 n
[Range] 0 ≤ n ≤ 255
[Default] n = 0
[Description] • Turns smoothing mode on or off.
•
When the LSB of n is 0, smoothing mode is turned off.
•
When the LSB of n is 1, smoothing mode is turned on.
GS f n
[Name] Select font for HRI characters
[Format] ASCII GS f n
Hex 1D 66 n
Decimal 29 102 n
[Range] For ANK/Multilingual model: n = 0, 1, 48, 49
For Japanese model: 0 ≤ n ≤ 2, 48 ≤ n ≤ 50
[Default] n = 0
[Description] • Selects a font for the HRI characters used when printing a bar code.
•
n specifies the font of the HRI characters as follows:
<For ANK/Multilingual model>
n Font
0, 48
Font A (12 × 24)
1, 49
Font B (9 × 17)
<For Japanese model>
n Font
0, 48
Font A (12 × 24)
1, 49
Font B (10 × 24)
2, 50
Font C (8 × 16)
