TM-T90
Specification
(STANDARD)
<Function 070> GS ( k p
L
p
H
cn fn m (fn = 70)
[Format] ASCII GS ( k p
L
p
H
cn fn m
Hex 1D 28 6B p
L
p
H
cn fn m
Decimal 29 40 107 p
L
p
H
cn fn m
[Range] (p
L
+ p
H
× 256) = 3 (p
L
= 3, p
H
= 0)
cn = 48
fn = 70
m = 0, 1
[Default] m = 0
[Description] • Specifies or cancels various PDF417 symbol options
•
When
m
= 0, the simple PDF417 symbol processing is canceled, and the standard PDF417
symbol processing is specified.
•
When m = 1, the simple PDF417 symbol processing is specified.
<Function 080> GS ( k p
L
p
H
cn fn m d1 …
……
… dk (fn = 80)
[Format] ASCII GS ( k p
L
p
H
cn fn m d1…dk
Hex 1D 28 6B p
L
p
H
cn fn m d1…dk
Decimal 29 40 107 p
L
p
H
cn fn m d1…dk
[Range] 4 ≤ (p
L
+ p
H
× 256) ≤ 65535 (0 ≤ p
L
≤ 255, 0 ≤ p
H
≤ 255)
cn = 48
fn = 80
m = 48
0 ≤ d ≤ 255
k = (p
L
+ p
H
× 256) – 3
[Description] • Stores symbol data (d1...dk) in the PDF417 symbol storage area.
•
Bytes of ((p
L
+ p
H
× 256) – 3) after m (d1…dk) are processed as symbol data.
