Epson TM-T90 - Function 065> GS ( K Pl Ph Cn Fn N (Fn = 65); Function 066> GS ( K Pl Ph Cn Fn N (Fn = 66)

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
153 152
TM-T90
Specification
(STANDARD)
<Function 065> GS ( k p
L
p
H
cn fn n (fn = 65)
[Format] ASCII GS ( k p
L
p
H
cn fn n
Hex 1D 28 6B p
L
p
H
cn fn n
Decimal 29 40 107 p
L
p
H
cn fn n
[Range] (p
L
+ p
H
× 256) = 3 (p
L
= 3, p
H
= 0)
cn = 48
fn = 65
0 ≤ n ≤ 30
[Default] n = 0
[Description] • Sets the number of columns of the data area for PDF417.
•
n = 0 specifies automatic processing.
•
When automatic processing (
n
= 0) is specified, the number of columns is calculated with
the number of code words based on the range of the printable area.
•
n
≠ 0 sets the number of columns of the data area to
n
code words.
[Notes] • The following data is not included in the number of columns.
•
Start and stop patterns
•
Left and right indicator code words
<Function 066> GS ( k p
L
p
H
cn fn n (fn = 66)
[Format] ASCII GS ( k
p
L
p
H
cn fn n
Hex 1D 28 6B
p
L
p
H
cn fn n
Decimal 29 40 107
p
L
p
H
cn fn n
[Range] (
p
L
+
p
H
× 256) = 3 (
p
L
= 3,
p
H
= 0)
cn
= 48
fn
= 66
n
= 0, 3 ≤
n
≤ 90
[Default]
n
= 0
[Description] • Sets the number of rows of data area for PDF417.
•
n
= 0 specifies automatic processing.
•
When automatic processing (
n
= 0) is specified, the number of rows is calculated with the
number of code words or the range of the printable area.
•
n ≠ 0 sets the number of rows to n.
