Epson TM-T90 Specification

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
155 154
TM-T90
Specification
(STANDARD)
<Function 069> GS ( k p
L
p
H
cn fn m n (fn = 69)
[Format] ASCII GS ( k p
L
p
H
cn fn m n
Hex 1D 28 6B p
L
p
H
cn fn m n
Decimal 29 40 107 p
L
p
H
cn fn m n
[Range] (p
L
+ p
H
× 256) = 4 (p
L
= 4, p
H
= 0)
cn = 48
fn = 69
m = 48, 49
48 ≤ n ≤ 56 (when m = 48 is specified)
1 ≤ n ≤ 40 (when m = 49 is specified)
[Default] m = 49, n = 1
[Description] • Sets the error correction level for PDF417 symbols.
• When
m
= 48, the error correction level is set by the “Level Setting” error correction code
word.
n Function Error correction code word
48 Select error correction level 0 2
49 Select error correction level 1 4
50 Select error correction level 2 8
51 Select error correction level 3 16
52 Select error correction level 4 32
53 Select error correction level 5 64
54 Select error correction level 6 128
55 Select error correction level 7 256
56 Select error correction level 8 512
• When
m
= 49, the error correction level is set to the level indicated by the data code word
value.
The rate is set to [n × 10%].
The error correction levels in the following table are determined by the calculation [Data
code word × n × 0.1 = (A)] (round up fractions of 0.5 and over and truncate others).
Result (A) Error correction level Error correction code word
0 - 3 Error correction level 1 4
4 - 10 Error correction level 2 8
11 - 20 Error correction level 3 16
21 - 45 Error correction level 4 32
46 - 100 Error correction level 5 64
101 - 200 Error correction level 6 128
201 - 400 Error correction level 7 256
401 or more Error correction level 8 512
