Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
146 145
TM-T90
Specification
(STANDARD)
<Function 67>
GS ( L
pL pH m fn a kc1 kc2 b xL xH yL yH [c d1....dk]1… [c d1....dk]b (fn = 67)
[Format] ASCII GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1... [c d1...dk]b
Hex 1D 28 4C pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1... [c d1...dk]b
Decimal 29 40 76 pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1... [c d1...dk]b
[Range]
GS ( L
parameters
12 ≤ (p
L
+ p
H
× 256) ≤ 65535 (0 ≤ p
L
≤ 255, 0 ≤ p
H
≤ 255)
GS 8 L
parameters
12 ≤ (p1 + p2 × 256 + p3 × 65536 + p4 × 16777216) ≤ 4294967295
(0 ≤ p1 ≤ 255, 0 ≤ p2 ≤ 255, 0 ≤ p3 ≤ 255, 0 ≤ p4 ≤ 255)
Common parameters for
GS ( L
/
GS 8 L
m
= 48
fn
= 67
a
= 48
32 ≤
kc1
≤
126
32 ≤
kc2 ≤ 126
b
= 1, 2
1 ≤ (x
L
+ x
H
× 256) ≤ 8192 (0 ≤ x
L
≤ 255, 0 ≤ x
H
≤ 32)
1 ≤ (y
L
+ y
H
× 256) ≤ 2304 (0 ≤ y
L
≤ 255, 0 ≤ y
H
≤ 9)
c = 49 (when the single-color paper is selected)
c = 50 (when the two-color paper is selected)
0 ≤
d
≤ 255
k
= (int ((
x
L
+
x
H
× 256) + 7) /8) × (
y
L
+
y
H
× 256)
• The total capacity of the NV user memory is selectable as any one of these: [0, 64K, 128K,
192K, 256K, 320K, 384K] bytes with
GS ( E
. The default value is 384KB.
[Description] • Defines the raster graphics data in the NV graphics area.
•
b specifies the number of the color of the defined data.
•
x
L
, x
H
specify the defined data in the horizontal direction as (x
L
+ x
H
× 256) dots.
•
y
L
, y
H
specify the defined data in the vertical direction as (y
L
+ y
H
× 256) dots.
•
c
specifies the color of the defined data.
c Defined data color
49 Color 1
50 Color 2
•
Color 1 means black (a high level of energy) on the specified two-color thermal paper.
•
Color 2 means red (a low level of energy) on the specified two-color thermal paper.
