TM-T90
Specification
(STANDARD)
•
Cover is open.
•
Printing stopped by paper end.
•
Recoverable error occurred.
•
Unrecoverable error occurred.
• When (
d
= 2, 50) is specified, the offline cause to be transmitted is the five bytes that follow:
•
First byte
Bit Off/On Hex Decimal Status
0 Off 00 0 No CPU execution error.
On 01 1 CPU execution error occurred.
1 Off 00 0 No read/write error in memory.
On 02 2 Read/write error in memory occurred.
2 Off 00 0 No read/write error in the gate array.
On 04 4 Read/write error in the gate array occurred.
3 ~ 5 -- -- -- Reserved.
6 On 40 64 Fixed.
7 Off 00 0 Fixed.
•
Second byte
Bit Off/On Hex Decimal Status
0 Off 00 0 No high voltage error.
On 01 1 High voltage error occurred.
1 Off 00 0 No low voltage error.
On 02 2 Low voltage error occurred.
2 Off 00 0 No overcurrent error.
On 04 4 Overcurrent error occurred.
3 ~ 5 -- -- -- Reserved.
6 On 40 64 Fixed.
7 Off 00 0 Fixed.
•
Third byte
Bit Off/On Hex Decimal Status
0 Off 00 0 No iInternal circuit connection error (thermostat).
On 01 1 Internal circuit connection error occurred (thermostat).
1 ~ 5 -- -- -- Reserved.
6 On 40 64 Fixed.
7 Off 00 0 Fixed.
•
Fourth byte
Bit Off/On Hex Decimal Status
0 Off 00 0 No autocutter error.
On 01 1 Autocutter error occurred.
1 Off 00 0 No roll paper cover open error (when [Msw8-8] is on).
On 02 2 Roll paper cover open error occurred (when [Msw8-8]
is on).
2 ~ 5 -- -- -- Reserved.
