Epson TM-T90 - Page 179

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
162 161
TM-T90
Specification
(STANDARD)
1st byte of DIP switch status information
Bit Off/On Hex Decimal Function
Off 00 0 DIP SW 1-1: Off
0
On 01 1 DIP SW 1-1: On
Off 00 0 DIP SW 1-2: Off
1
On 02 2 DIP SW 1-2: On
Off 00 0 DIP SW 1-3: Off
2
On 04 4 DIP SW 1-3: On
Off 00 0 DIP SW 1-4: Off
3
On 08 8 DIP SW 1-4: On
4 Off 00 0 Reserved.
5 Off 00 0 Reserved.
6 On 40 64 Fixed.
7 Off 00 0 Fixed.
2nd byte of DIP switch status information
Bit Off/On Hex Decimal Function
Off 00 0 DIP SW 1-5: Off
0
On 01 1 DIP SW 1-5: On
Off 00 0 DIP SW 1-6: Off
1
On 02 2 DIP SW 1-6: On
Off 00 0 DIP SW 1-7: Off
2
On 04 4 DIP SW 1-7: On
Off 00 0 DIP SW 1-8: Off
3
On 08 8 DIP SW 1-8: On
4 Off 00 0 Reserved.
5 Off 00 0 Reserved.
6 On 40 64 Fixed.
7 Off 00 0 Fixed.
[Note] • When memory switch Msw 8-7 is On, the printer model ID is 32, and the firmware version ID
is 70.
[Reference] APPENDIX H
