Epson TM-T90 Specification

Confidential
EPSON
TITLE SHEET
REVISION
NO.
SHEET NEXT
F
TM-T90
Specification
(STANDARD)
3 2
ANK/Multilingual Model Japanese Model
7) Print speed
Normal 170 mm/s {6.69"/s} maximum 170 mm/s {6.69"/s} maximum
Ladder bar code or
two-dimensional code
printing
100 mm/s {3.94"/s} maximum 90 mm/s {3.54"/s} maximum
Printing with four-part
energizing
70 mm/s {2.76"/s} maximum 70 mm/s {2.76"/s} maximum
Two-color printing 100 mm/s {3.94"/s} maximum 90 mm/s {3.54"/s} maximum
NOTES: • The print speed listed above is the value when the printer
prints with the default print density level at 24 V and 25°C
{77°F}. The print speed may change automatically with the
condition of the supply voltage or the head temperature.
• Printing speed may be slower, depending on the data
transmission speed and the combination of control
commands.
• The four-part energizing mode can be selected with the
memory switch. If the power supply is a power-savings
type with lower capacity, the printer can print with the
four-part energizing mode set.
• Low transmission speed may cause intermittent printing. It
is recommended to transmit data to the printer as quickly as
possible. (Example: at least 19200 bps for printing with
Font A) (bps: bits per second)
• When a ladder bar code or 2-dimensional code is printed,
the print starts when the specific paper feed speed is
reached. Therefore, the paper may be fed for the
maximum 10 dot lines, depending on the paper feed speed
at the time that the print data is received.
4.23 mm {1/6"} 3.75 mm {0.148"} 8) Line spacing
NOTE: Programmable by command.
