3) Character size (Character area):
<ANK/Multilingual model>
Table 1.2.1 Character Size for ANK/Multilingual Model
Standard Double-height Double-width
Double-width /
Double-height
W × H (mm) W × H (mm) W × H (mm) W × H (mm)
Font A 12 × 24 1.692 × 3.384 1.692 × 6.768 3.384 × 3.384 3.384 × 6.768
Font B 9 × 17 1.269 × 2.397 1.269 × 4.794 2.538 × 2.397 2.538 × 4.794
Kanji font A 24 × 24 3.384 × 3.384 3.384 × 6.768 6.768 × 3.384 6.768 × 6.768
Thai characters 12 × 72 1.692 × 10.152 1.692 × 20.304 3.384 × 10.152 3.384 × 20.304
Thai characters 9 × 51 1.269 × 7.191 1.269 × 14.382 2.538 × 7.191 2.538 × 14.382
NOTES: 1. The actual print character may be smaller than the size shown in the table above,
because the above size includes spaces in the font.
2. Characters can be scaled up to 64 times as large as the standard size.
3. Character size not including the horizontal spacing in the standard scale is as follows:
Font A (12 × 24): 1.25 (W) × 3.0 (H) mm
Font B (9 × 17): 0.88 (W) × 2.13 (H) mm
(ANK = alphanumeric)
<Japanese model>
Table 1.2.2 Character Size for Japanese Model
Standard Double-height Double-width
Double-width /
Double-height
W × H (mm) W × H (mm) W × H (mm) W × H (mm)
Font A 12 × 24 1.50 × 3.0 1.50 × 6.0 3.0 × 3.0 3.0 × 6.0
Font B 10 × 24 1.25 × 3.0 1.25 × 6.0 2.5 × 3.0 2.5 × 6.0
Font C 8 × 16 1.0 × 2.0 1.0 × 4.0 2.0 × 2.0 2.0 × 4.0
Kanji font A 24 × 24 3.0 × 3.0 3.0 × 6.0 6.0 × 3.0 6.0 × 6.0
Kanji font B 20 × 24 2.5 × 3.0 2.5 × 6.0 5.0 × 3.0 5.0 × 6.0
Kanji font C 16 × 161 2.0 × 2.0 2.0 × 4.0 4.0 × 2.0 4.0 × 4.0
NOTES: 1. The actual print character may be smaller than the size shown in the table above,
because the above size includes spaces in the font.
2. Characters can be scaled up to 64 times as large as the standard size.
3. Character size not including the horizontal spacing in the standard scale is as follows:
Font A (12 × 24): 1.25 (W) × 3.0 (H) mm
Font B (10 × 24): 1.0 (W) × 3.0 (H) mm
