EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 278
Confidential
DISASSEMBLY FLOWCHART
Start
Rear Cover (Back)
(→P. 280)
ASF Front Cover
(→P. 281)
Housing Upper
(→P. 283)
Housing Left
(→P. 282)
Cable Guide
(→P. 284)
Hinge Lower Cover
(→P. 283)
Ink Eject Cover
(→P. 281)
Housing Right
(→P. 282)
Peel off the CRCM FFC
(→P. 285)
Plate
(→P. 285)
Guide Cover
(→P. 286)
RIPS Unit
(→P. 286)
D14
Ink Supply Unit
(→P. 289)
Ink Tube Guide Holder
(→P. 290)
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.
 Implement the procedure indicated by when
removing the Ink Tube from the RIPS Unit and
Printhead.
Foot
(→P. 288)
Ink Leak Sensor
(→P. 289)
A1
E1
B1
F1
C1
D1
A2
E2
B2
F2
C2
D2
A3
E3
B3
F3
C3
D3
A4
E4
B4
F4
C4
D4
A5
E5
B5
F5
C5
D5
A6
E6
B6
F6
C6
D6
A7
E7
B7
F7
C7
D7
A8
E8
B8
F8
C8
D8
A9
E9
B9
F9
C9
D9
A10
E10
B10
F10
C10
D10
A11
E11
B11
F11
C11
D11
A12
E12
B12
F12
C12
D12
a
A13
a
E13
C13
RIPS Unit Lower
(→P. 290)
RIPS Cover Lock
Lever(→P. 291)
F13
D13
E14
E15
Ink Porous Pad
(→P. 292)
F15
C14
F14
B13
Preparation for
Dissembling
Ink Discharge
(→P. 279)
Start
