7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 108 Revision 1.1.3
7.22.1.5. Gain Adjust Y
The Gain Adjust Y control enables the user to set the value of the gain for the selected source. The user
can adjust the gain of the selected source by moving the associated slider control left to decrease the
value or right increase the value. The value range for the gain adjustments is -24 dB to +24 dB. Gain is
adjusted in 0.1 dB increments.
7.22.1.6. Invert Enable Y
This control enables the user to invert the phase or pass the selected audio channels. The Invert Enable
Y drop down menu appears as follows:
Normal
Pass the audio channel through with no processing.
Invert
Invert the phase of the audio channel.
