7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 139
7.33. PRESETS CONTROL TAB
The Presets Control tab is used to control the presets. The user can configure the Recall Preset, Store
User Preset, and enable/disable the Auto Recall Presets functions.
Figure 7-41: Utilities Control Tab
7.33.1. Preset Control
The 7814 series of converters can manage 10 user presets.
These 10 presets can store the complete set of card controls.
There may be a slight disturbance in the operation of the card while the new preset is
being recalled.
