evertz MultiFrame 7814 Series - Table 9-3: Vistalink Trap Parameters

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 157
9.4. VISTALINK
®
TRAPS
The 7814UDX-HD-2 modules will raise a VistaLINK
®
trap if the temperature of the main or sub cards rises
above > 78 °F.
Parameter
Description
Page
AFD Loss
Displays the status of the AFD loss trap. 57
Audio Group 1
Displays the status of audio group 1 presence 80
Audio Group 2
Displays the status of audio group 2 presence 80
Audio Group 3
Displays the status of audio group 3 presence 80
Audio Group 4
Displays the status of audio group 4 presence 80
CEA708 Service 1 to CEA708 Service
16 Not Present
Displays the trap status of CEA708 Service 1 to 16.
132
Cooling Fan Module 1
Displays the status of the top on-board cooling fan 27
Cooling Fan Module 2
Displays the status of the bottom on-board cooling fan 27
External Genlock Std Enable
Displays the status of the external Genlock Standard 29
Genlock Valid
Displays the validity of the genlock input 43
IG Loudness Level Threshold Critical
Displays the status of the critical threshold limit 127
IG Loudness Level Threshold Major
Displays the status of the major threshold limit 127
IG Loudness Level Threshold Minor
Displays the status of the minor threshold limit 127
PGM IN A
Displays the status of input video to PGM IN A DIN 43
PGM IN B
Displays the status of input video to PGM IN B DIN 43
SD CC1 to SD CC3 Not Present
Displays the trap status of Standard Definition Closed
Captioning for captions 1 to 3.
132
Temperature
Displays the status of the temperature trap. 27
Table 9-3: VistaLINK
®
Trap Parameters
