7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 146 Revision 1.1.3
9.2. VISTALINK
®
MONITORED PARAMETERS
The following parameters can be remotely monitored through the VistaLINK
®
interface.
Audio Delay
Displays the delay of the audio in ms. 80
CDP 708 Demux Parser
Displays the status of CDP 708 Demux Closed Caption
reading.
134
CDP Parser
Displays the status of Closed Caption reading. 134
De-Interlacer Operating Mode
Reports the current operating mode of the deinterlacer. 54
Embedder Group 1 Input
Displays is audio is detected in Audio Group 1 80
Embedder Group 2 Input
Displays is audio is detected in Audio Group 2 80
Embedder Group 3 Input
Displays is audio is detected in Audio Group 3 80
Embedder Group 4 Input
Displays is audio is detected in Audio Group 4 80
Gain Applied
Reports a real time value indicating the amount of gain
being applied by the IntelliGain system. Values
124
Genlock Standard
Reports if a valid video reference has been supplied to the
REF IN DIN and indicates the standard that is detected
when a valid reference is applied.
129
Global Status: Genlock Standard
Reports if a valid video reference has been supplied to the
selected reference input
29
Input Loudness
Reports a real time value of the calculated input loudness
value.
124
Input SMPTE2016-1 Code Status
Reports any detected AFD values on the incoming video
signal.
58
Input Video Source
Reports what input source has been selected to pass
through the main up/down/cross conversion path.
43
Integrated Loudness
Reports a real time value of the calculated integrated
loudness value.
125
Loudness Range
Reports a real time value of the calculated loudness range
value within the duration of the Integrated Loudness
calculation.
125
Loudness Range High
Reports a real time value of the highest calculated loudness
value within the duration of the Integrated Loudness
calculation.
125
Loudness Range Low
Reports a real time value of the lowest calculated loudness
value within the duration of the Integrated Loudness
calculation,
125
Maximum Loudness
Reports a real time value of the calculated maximum
loudness value within the duration of the Integrated
Loudness calculation
125
