evertz MultiFrame 7814 Series - Table 9-2: Vistalink; Controlled Parameters

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 156 Revision 1.1.3
PGM IN A Source (-F
Option Only)
The PGM IN A source
control is used to select
whether the Input video for
PGM IN A is to be source
by the SDI input of the
Fiber input. To source this
input with the DIN
connector on the rear-
plate select SDI. To
source this input with the
Fiber input select Fiber in
the drop-down menu.
9.3.1.2. PGM IN B
Source (-F
Option Only)
The PGM IN B source
control is used to select
whether the Input video for
PGM IN B is to be source
by the SDI input of the
Fiber input. To source this
input with the DIN
connector on the rear-
plate select SDI. To
source this input with the
Fiber input select Fiber in
the drop-down menu.
Video Input Source
Selects source of video input. 40
Video Standard Input
Selects the video input standard. 39
Video Standard Output
Selects the video output standard. 40
VITC Read
Select decode line for VITC. SD input only. 130
VITC Write
Select line for VITC insert. SD output only. 130
Y Gain
Varies the Source Y. 45
Y Offset (Black Level)
Varies the Source Y. 45
Table 9-2: VistaLINK
®
Controlled Parameters
