evertz MultiFrame 7814 Series - Video Control

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 39
7.1.1. Video Control
7.1.1.1. Video Standard Input
This option selects the input video standard being used. Interlaced video formats are shown with the
number of fields per second. Progressive formats are shown with the number of frames per second. The
module is not capable of converting between 59.94/60 Hz and 50 Hz related frame rates. The drop down
menu for Video Std Input appears as follows:
When the input standard is set to Auto, the module will auto detect the video standard.
The full set of available input video standards includes:
* For -3G versions only.
Auto
1080i/59.94
720p/59.94
525i/59.94
1080i/50
720p/50
625i/50
1080p/59.94 (425M level A) *
1080p/59.94 (425M level B) *
1080p/50 (425M level A) *
1080p/50 (425M level B) *
