evertz MultiFrame 7814 Series - Page 154

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 140 Revision 1.1.3
7.33.1.1. Recalling Configurations from the User Presets
This control is used to initiate a recall of the card configuration from one of the user presets or reset the
card to factory defaults.
There are 10 user presets to recall.
None
No Presets will be recalled
Default
All controls for the card will revert to defaults
Preset 1
Recall User Preset 1
Preset 2
Recall User Preset 2
Preset 3
Recall User Preset 3
Preset 4
Recall User Preset 4
Preset 5
Recall User Preset 5
Preset 6
Recall User Preset 6
Preset 7
Recall User Preset 7
Preset 8
Recall User Preset 8
Preset 9
Recall User Preset 9
Preset 10
Recall User Preset 10
7.33.1.2. Storing Configurations from the User Presets
This control is used to initiate a store of the current card configuration into one of the user presets. To
store a card configuration to a specific preset, select the preset to which you wish to store the card
settings and press the APPLY button. There are 10 presets to which you can store.
None
No Presets will be stored
Preset 1
Store to User Preset 1
Preset 2
Store to User Preset 2
Preset 3
Store to User Preset 3
Preset 4
Store to User Preset 4
Preset 5
Store to User Preset 5
Preset 6
Store to User Preset 6
Preset 7
Store to User Preset 7
Preset 8
Store to User Preset 8
Preset 9
Store to User Preset 9
Preset 10
Store to User Preset 10
