7.33.1.3. Auto Recall Presets for Specific Video Input Standard
The Auto Recall Presets functionality is used to automatically recall card configurations for specific video
inputs. The user must define this format dependant card configurations using VistaLINK
®
PRO. Once this
is complete, they will automatically be recalled once that particular input is detected on the module itself.
To utilize this functionality, the following steps must be performed:
1) Enable the Presets functionality in the Utilities control tab by selecting the dropdown beside the
desired user preset.
2) Set the input standard for which you wish to define the card preset.
3) Proceed to configure as desired ensuring that you press APPLY each time a parameter is
changed.
4) Repeat steps 2-3 for each input video standard
Disable
Auto Recall Presets functionality is disabled.
1080i/59.94
Each time 1080i/59.94 video is detected on the input the module will
automatically recall the defined preset for the input video standard.
720p/59.94
Each time 720p/59.94
video is detected on the input the module will
automatically recall the defined preset for the input video standard.
525i/59.94
Each time 525i/59.94 vi
deo is detected on the input the module will
automatically recall the defined preset for the input video standard.
1080i/50
Each time 1080i/50 video is detected on the input the module will automatically
recall the defined preset for the input video standard.
720p/50
Each time 720p/50 video is detected on the input the module will automatically
recall the defined preset for the input video standard.
625i/50
Each time 625i/50 video is detected on the input the module will automatically
recall the defined preset for the input video standard.
1080p/59.94A
Each time 1080p/59.94A
video is detected on the input the module will
automatically recall the defined preset for the input video standard.
1080p/59.94B
Each time 1080p/59.94B video is detected on the inp
ut the module will
automatically recall the defined preset for the input video standard.
1080p/50A
Each time 1080p/50A
video is detected on the input the module will
automatically recall the defined preset for the input video standard.
1080p/50B
Each time 1080p/50B
video is detected on the input the module will
automatically recall the defined preset for the input video standard.

NOTE:
The Auto Recall Presets functionality should be used with care.
All card parameters are recalled when a input standard is detected. When a new input
standard is detected, a new value for that particular card parameter may be recalled.
Parameters must be specifically set for each the video input standards if you desire the
same parameter value to be recalled all the time.
