7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 112 Revision 1.1.3
7.24.1.2. Gain Adjust X
The Gain Adjust X control enables the user to set the value of the gain for the selected source. The user
can adjust the gain of the selected source by moving the associate slider control left to decrease the value
or right to increase the value. The value range for the gain adjustments is -24 dB to +24 dB. Gain is
incremented or decremented in 0.1 dB steps.
7.24.1.3. Invert Enable X
This control enables the user to invert the phase or pass the selected audio channel. The Invert Enable X
drop down menu appears as follows:
Normal
Pass the audio channel through with no processing.
Invert
Invert the phase of the audio channel.
