7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 22 Revision 1.1.3
General
Contains status traps for module operation including Module temperature,
Cooling Fan Module 1 and Cooling Fan Module 2. A m
description can be found in later sections of this manual.
Reference Control
Tab
Selects the source of the card genlock. Selects which reference input is to
be used (e.g. Card, Frame Ref 1/2). A more detailed description can be
found in later sections of this manual.
IP
Config
uration for defining the IP address, subnet mask and default gateway
for the card’s Ethernet port. At the time of this manual’s writing, the Ethernet
port is only used for use with a mini-agent for VistaLINK®. A more detailed
description can be found in later sections of this manual.
Change Product
Some options can be purchased from sales and added to the 7814 without
hardware upgrades. A m
ore detailed description can be found in later
sections of this manual.
GPIO
Contains controls for setting up and c
onfiguring the GPIO interface on the
rear plate. Each GPIO can be configured as either an input or output. GPIO
Status information is also available on this Tab.
Fiber
(-F option Only)
The Fiber control Tab gives monitoring ability for the SFP modules inserted
into the rear-
plate. These include SFP part number, Firmware, Version,
Laser Rx receive power and Laser Tx wavelengths. Fiber traps are also
configured on this Tab.
