INTRODUCTION
SERVICE SPECIFICATIONS
11
ELECTRICAL
HP 115 150, 175, 200
Minimum Battery
Requirements
675 CCA (845 MCA); or
750 CCA (940 MCA) below 32°F (0°C)
(Use a 107 amp-hr battery for extreme applications.)
Alternator Dual Voltage 50 Amp with Voltage Regulator and Battery Isolation
Tachometer Setting 6 pulse (12 pole)
Charging Isolator Integral, Terminal on Engine Harness
Engine Fuses P/N 967545 – 10 A
COOLING
Thermostat 143°F (62°C)
Maximum Temperature 230°F (110°C) Below 3000 RPM and 194°F (90°C) Above 3000 RPM
Water pressure 21 psi minimum @ 3000 RPM
IGNITION
Type Capacitor Discharge
Firing Order 1-2-3-4 1-2-3-4-5-6
Ignition Features EMM Controlled
RPM Limit 6250
Crankshaft Position Sensor Air
Gap
Fixed
Spark Plug
Refer to Emission Control Information Label
Champion
†
QC10WEP @ 0.028 ± .003 in. (0.76 mm)
Refer to Emission Control Information Label
GEARCASE
Gear Ratio
V4 “S” Type Gearcase: 13:26 (.500) (2:1)
V4 “O” Type Gearcase: 12:27 (.444) (2.25:1)
V6 “M” Type Gearcase: 13:24 (.542) (1.85:1)
V6 “O” Type Gearcase: 14:26 (.538) (1.86:1)
V6 “L” Type Gearcase: 14:26 (.538) (1.86:1)
Refer to GEARCASE TYPES on p. 305
Lubricant HPF XR Gearcase Lubricant
Capacity
“S” Type Gearcase: 31.6 fl. oz. (935 ml)
V4 “M” Type Gearcase: 43.0 fl. oz. (1270 ml)
V6 “M” Type Gearcase: 44.0 fl. oz. (1300 ml)
“M” Type – Counter Rotation: 41 fl. oz. (1220 ml)
“O” Type Gearcase: 33.1 fl. oz. (980 ml)
“L” Type Gearcase: 33.1 fl. oz. (980 ml)
Refer to GEARCASE TYPES on p. 305
Shift Rod Height
20 in. (L) Models: 20.945 (532 mm) ± one-half turn
25 in. (X) Models: 25.945 (659 mm) ± one-half turn
Shift Cable Stroke 1.125 to 1.330 in. (28.6 to 33.8 mm) measured between NEUTRAL and FORWARD
POWER TRIM/TILT
Lubrication
115 (Single Piston style): Evinrude/Johnson Biodegradeable TNT Fluid
115-200 (Three Piston style): Evinrude/Johnson Power Trim/Tilt & Power Steering
Fluid or GM Dextron
†
II Automatic Transmission Fluid
Fluid Capacity 21 fl. oz. (622ml)
Trim Range 0° to 21°
Tilt Range 22° to 75°
