90
ENGINE COVER SERVICE
UPPER COVER SERVICE
UPPER COVER SERVICE
Latch Hook Installation
Insert threaded bracket into pocket.
Apply Ultra-Lock to screw threads. Place hook
into position. Tighten screws to a torque of 60 to
84 in. lbs. (7 to 9.5 N·m).
Upper Cover Cap Replacement
Place new upper cap into position.
Tighten self-tapping screws to a torque of 24 to 36
in. lbs. (2.7 to 4 N·m).
1. Bracket 006826
006819
1
006815
1. Upper cap screws 006820
11
To Next Page
