251
POWERHEAD
POWERHEAD INSTALLATION
11
Installation
Place mount assemblies in position, with flats fac-
ing away from each other.
Apply Moly Lube to all sides of retainer and install
between mounts.
Install the retainer screw and tighten to a torque of
15 to 20 ft. lbs. (20 to 27 N·m).
POWERHEAD
INSTALLATION
Apply Permatex No. 2 to both sides of a new base
gasket around the exhaust port only. Install gasket
on adapter. To ensure proper sealing, mating sur-
faces must be clean and dry.
IMPORTANT: V4 and V6 base gaskets are
NOT interchangeable. Be sure to use the correct
part.
Coat the driveshaft splines with Moly Lube. Do not
apply lubricant to end of driveshaft.
Use Lifting Tool, P/N 342672, and hoist to slowly
lower powerhead onto exhaust housing. If neces-
sary, rotate flywheel in a clockwise direction to
align crankshaft and driveshaft splines.
005310
1. Mount retainer screw 005309
1
1. Permatex No. 2 005258
005276
1
