10
INTRODUCTION
SERVICE SPECIFICATIONS
SERVICE SPECIFICATIONS
ENGINE
HP 115 150, 175, 200
Full Throttle
Operating Range
5500–6000 RPM 4850–5850 RPM
Power 115 HP: (85.8 kw) @ 5750 RPM
150 HP: (111.9 kw) @ 5350 RPM
175 HP: (130.5 kw) @ 5350 RPM
200 HP: (149.1 kw) @ 5350 RPM
Idle RPM in Gear 550 ± 50 500 ± 50
Test Propeller
V4 20 in. (L) Models: P/N 386246 or P/N 433068
V4 25 in. (X) and V6 Standard Rotation Models: P/N 387388
V6 Counter Rotation Models: P/N 398673
Weight
(may vary depending
on model)
20 in. (L) Models: 375 lbs. (170 kg)
25 in. (X) Models: 390 lbs. (177 kg)
20 in. (L) Models: 418 lbs. (190 kg)
25 in. (X) Models: 433 lbs. (196 kg)
Lubrication
Evinrude/Johnson XD100 Oil or Evinrude/Johnson XD50 Oil
Refer to Oil Requirements on p. 66
Engine Type 60° V 4-Cylinder Loop-Charged 60° V 6-Cylinder Loop-Charged
Displacement
105.4 cu. in. (1727 cm
3
) 158.2 cu. in. (2592 cm
3
)
Bore 3.601 in (91.47 mm)
Stroke 2.588 in. (65.74 mm)
Standard Bore 3.6005 to 3.6015 in. (91.45 to 91.48 mm)
Top Crankshaft Journal 2.1870 to 2.1875 in. (55.55 to 55.56 mm)
Center Crankshaft Journals 2.1870 to 2.1875 in. (55.55 to 55.56 mm)
Bottom Crankshaft Journal 1.5747 to 1.5752 in. (40.0 to 40.01 mm)
Rod Crankpin 1.3757 to 1.3762 in. (34.94 to 34.96 mm)
Piston Ring End Gap, Both 0.011 to 0.023 in. (0.28 to 0.58 mm)
FUEL
Fuel/Oil Ratio EMM Controlled
Starting Enrichment EMM Controlled
Preferred Fuel Regular unleaded gasoline
Acceptable Fuel See Fuel Requirements on p. 65 for additional information.
Minimum (High) Fuel Pressure
@ IDLE RPM – 500 ± 50
22 to 28 psi (152 to 193 kPa)
Minimum Fuel Lift Pump Pressure
@ IDLE RPM – 500 ± 50
3 to 4 psi (21 to 28 kPa)
Maximum Fuel Inlet Vacuum 4 in. Hg. (13.5 kPa)
Minimum Octane 87 AKI (R+M)/2 or 90 RON
Additives
2+4
®
Fuel Conditioner, Fuel System Cleaner
Use of other additives may result in engine damage.
See Fuel Requirements on p. 65 for additional information.
