51 Fuel injector circuit #1 OPEN LED 2: ON (Running) - 10 seconds
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
52 Fuel injector circuit #2 OPEN LED 2: ON (Running) - 10 seconds
53 Fuel injector circuit #3 OPEN LED 2: ON (Running) - 10 seconds
54 Fuel injector circuit #4 OPEN LED 2: ON (Running) - 10 seconds
55 Fuel injector circuit #5 OPEN LED 2: ON (Running) - 10 seconds
56 Fuel injector circuit #6 OPEN LED 2: ON (Running) - 10 seconds
57 High RPM with low TPS setting
33
LED 3: FLASHING
CHECK ENGINE
(FLASHING)
10 seconds
TPS < 5% and RPM > 3000. Engine SHUTDOWN. Will NOT restart until code has been cleared. The problem could be caused by
uncontrolled fuel entering the engine. DO NOT attempt to start the outboard until the problem has been found and repaired.
58 Operating temperature not reached (port) LED 3: OFF (Cranking) / ON (Running) - 10 minutes
Engine temperature < 122°F (50°C) with engine speed < 1000 RPM.
Check thermostat and pressure relief valve.
59 Operating temperature not reached (stbd) LED 3: OFF (Cranking) / ON (Running) - 10 minutes
Engine temperature < 122°F (50°C) with engine speed < 1000 RPM.
Check thermostat and pressure relief valve.
61 Fuel injector circuit #1 SHORTED LED 2: ON (Running) - 10 seconds
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
62 Fuel injector circuit #2 SHORTED LED 2: ON (Running) - 10 seconds
63 Fuel injector circuit #3 SHORTED LED 2: ON (Running) - 10 seconds
64 Fuel injector circuit #4 SHORTED LED 2: ON (Running) - 10 seconds
65 Fuel injector circuit #5 SHORTED LED 2: ON (Running) - 10 seconds
66 Fuel injector circuit #6 SHORTED LED 2: ON (Running) - 10 seconds
67 Engine Temperature Sensor circuit fault (stbd) LED 3: OFF (Cranking) / ON (Running) - 10 seconds
Engine Temperature < -13° F (-25° C), or > 329° F (165° C).
Check 5 V circuit and ground (NEG), and sensor resistance—9000 to 11000
Ω @ 77°F (25°C).
68 Engine Temperature BELOW range (stbd) LED 3: OFF (Cranking) / ON (Running) - 10 seconds Engine Temperature < -4° F (-20° C). Check engine temperature and sensor resistance.
69 Engine Temperature ABOVE range (stbd)
3
LED 4: ON (Running) WATER TEMP/HOT 10 seconds
Engine Temperature ≥ 212°F (100°C) below 2000 RPM or ≥ 194°F (90°C) above 2000 RPM.
Engine limited to 1200 RPM. Check cooling system.
71 Oil pressure circuit sensor fault detected LED 3: ON (Running) - 10 seconds < 0.15 V , > 4.85 V
72 Oil pressure BELOW expected range LED 3: ON (Running) - 10 seconds < 0.4 V
73 Oil pressure ABOVE expected range LED 3: ON (Running) - 10 seconds > 4.6 V
74 Water pressure sensor circuit fault detected LED 3: ON (Running) - 10 seconds < 0.15 V , > 4.85 V
75 Water pressure BELOW expected range LED 3: ON (Running) - 10 seconds < 0.4 V
76 Water pressure ABOVE expected range LED 3: ON (Running) - 10 seconds > 4.6 V
77 S.A.C. overcurrent fault
3
LED 1: OFF (Key On) / ON (Running) - 10 instances SAC current > 2 amps and/or < 20 V. Check for shorted 55 V wiring (injector circuits). Check for pinched or chaffed wiring.
78 Analog 5V circuit overload detected
3
LED 3: ON (Running) - 10 seconds Sensor voltage < 4.75 V. Check sensors and related wiring. Check for pinched or chaffed wiring.
79 Starter solenoid circuit OPEN LED 3: OFF (Key On) / ON (Running) CHECK ENGINE 10 seconds Check starter solenoid circuit for continuity (key switch OFF) and for 12 V with key switch ON.
81 Ignition timing circuit #1 OPEN LED 2: ON (Running) - 16 instances
EMM counts failed ignition events (crankshaft revolutions). Check circuit resistance.
82 Ignition timing circuit #2 OPEN LED 2: ON (Running) - 16 instances
83 Ignition timing circuit #3 OPEN LED 2: ON (Running) - 16 instances
84 Ignition timing circuit #4 OPEN LED 2: ON (Running) - 16 instances
85 Ignition timing circuit #5 OPEN LED 2: ON (Running) - 16 instances
86 Ignition timing circuit #6 OPEN LED 2: ON (Running) - 16 instances
87 Exhaust pressure circuit fault
3
LED 3: ON (Running) - 10 seconds < -85 in. water or > 85 in. water. Check for plugged or pinched hose or exhaust fitting.
88 Exhaust pressure BELOW expected range
3
LED 3: ON (Running) - 10 seconds < 40 in. water
89 Exhaust pressure ABOVE expected range
3
LED 3: ON (Running) - 10 seconds > 80 in. water
91 Fuel pump circuit OPEN LED 2: ON (Running) - 10 seconds
Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
92 Exhaust valve solenoid OPEN (V4) LED 2: ON (Running) - 10 seconds Refer to exhaust valve relay tests.
94 Fuel pump circuit SHORTED LED 2: ON (Running) - 2 seconds Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
97 Intermittent switched B+ detected LED 3: ON (Running) - 10 seconds Switched battery voltage < 7 V. Check connections and wiring
NOTE: Always note service codes before clearing codes. Clear stored codes using diagnostic software. Clearing some codes requires turning EMM “OFF” and then “ON” again.
CODE
EMM CIRCUIT/SENSOR
INTERNAL
SENSOR
S.A.F.E
SHUT
DOWN
EMM LED DISPLAY
DASHBOARD
GAUGE WARNING
DISPLAY
TIME TO
ACTIVATE
SENSOR: CIRCUIT VOLTAGE / RESISTANCE (Ω) / INFORMATION
page 2
Rev 01/08
