SMP 300 Series • Remote Communication and Control 115
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Information Requests (continued)
Query eth0 link status 13I Current link state (up/down)* speed in MB (10/100/1000)* mode
(full/half)
].
Query file transfer config
38I
Example: \\Network_Storage\Folder, cifs
].
Query selected input
status
42I
Example:
Example:
ChA<In#>*<input name>*<input resolution>*<frame
rate>*<1/0>,ChB<In#>*<input name>*<input
resolution>*<frame rate>*<1/0>
]
ChA1*Input1Name*1920x1080*60*1,ChB3*Input3Name*
720x480*60*1
]
ChA*Input1Name*n/a*n/a*0,ChB4*Input4Name*
1920x1080*50*1
]
Query Archive/ChA
encoder presets
43I <DefaultPreset#>*<DefaultPresetName>,
<SelectedPreset#>*<SelectedPresetName>
]
Query CHB encoder
presets (Dual Channel
only)
44I <DefaultPreset#>*<DefaultPresetName>,
<SelectedPreset#>*<SelectedPresetName>
]
Query Confidence
encoder presets
45I
Example:
Example:
<DefaultPreset#>*<DefaultPresetName>,
<SelectedPreset#>*<SelectedPresetName>
]
3*720 High,1*1080p High
]
 saved
]
Query Archive/ChA
streaming presets
46I
<SelectedPreset#>*<SelectedPresetName>
]
Query ChB streaming
presets
47I
<SelectedPreset#>*<SelectedPresetName>
]
Query Confidence
streaming presets
48I
Example:
Example:
<SelectedPreset#>*<SelectedPresetName>
]
3*RTMPYouTube
]
 saved
]
Query layout preset
49I
Example:
<DefaultPreset#>*<DefaultPresetName>,
<SelectedPreset#>*<SelectedPresetName>
]
3*PBP Mid LFT,7*Side By Side
]
Storage Info
Query internal
55I Internal*<used>*<total>*free>*<recording_time>
*<active>
]
Query front USB
56I <name>*<used>*<total>*free>*<recording_time>*
<active>,<name>*<used>*<total>*free>*
<recording_time>*<active>...
]
Query rear USB
57I <name>*<used>*<total>*free>*<recording_time>*
<active>,<name>*<used>*<total>*free>*
<recording_time>*<active>...
]
Query RCP USB
58I <name>*<used>*<total>*free>*<recording_time>*
<active>,<name>*<used>*<total>*free>*
<recording_time>*<active>...
]
NOTES:
• For all USB ports, each new <name> field signifies a new partition on that USB drive, and are separated by a comma (,).
• For the <active> field, the device will respond with 0, 1, or 2: 0 = not active, 1 = single recording active, 2 = secondary recording active.
Query installed FlexOS
app or apps (firmware
v3.00 or newer)
60I <app name>*<ver#>*<enable/disable>
]
run state enable = 1
<app name>*<ver#>*<enable/disable>
]
run state disable = 0
<app name>*<ver#>*<enable/disable>
]]
Example: Digital I/O*2.08.0013*0
]
Panopto*1.00.0002*1
]]
Sync Schedule
Trigger schedule sync E
STRGR
}
TrgrS
] Sync with schedule (return error
code if scheduling is off or not
supported)
Unsolicited response
TrgrS
] Schedule is refreshed.
