SMP 300 Series • Front Panel Operations 25
Power Up Procedure
NOTE: Before powering the SMP300 Series, ensure that all necessary devices are
connected properly. Devices do not need to be powered.
Connect the power cord to a 100 to 240 VAC supply (see Power Connection on
page16). The unit undergoes self testing during the boot sequence (see figure11 and
figure12). After the sequence is complete (and when the device is not being configured or
has an active alarm), the default display cycle is on the LCD display.
EXTRON
ELECTRONICS
2
sec.
EXTRON
SMP 35x FW V1.06
45
sec.
SMP 35x
INITIALIZING
LOADING
FIRMWARE
30
sec.
~4
sec.
Power
On
Default Display Cycle
2
sec.
HH:MM:SS
TIME RECORD
2
sec.
2 sec.
In 1 1024x768@60
In 3 720p@60
2 sec.
ARCHIVE 5.0 MB
1280x720@30 fps
HH:MM:SS
TIME REMAIN
Figure 11. Boot Sequence and Default Display Cycle for Composite Mode
NOTE: The information shown in the default display cycle differs depending on
the active input and the type of video signal. Time Record only displays during a
recording. Time Remain displays the remaining time in the event and the estimated
recording time available during an unscheduled recording.
EXTRON
ELECTRONICS
2
sec.
EXTRON
SMP 35x FW V1.06
45
sec.
SMP 352
INITIALIZING
LOADING
FIRMWARE
30
sec.
~4
sec.
Power
On
Default Display Cycle
2
sec.
HH:MM:SS
TIME RECORD
2
sec.
2 sec.
In 1 1024x768@60
In 3 720p@60
2 sec.
CHA 5.0 MB
1280x720@30 fps
HH:MM:SS
TIME REMAIN
CHB 5.0 MB
1280x720@30 fps
2 sec.
2 sec.
Figure 12. Boot Sequence and Default Display Cycle for Dual Channel Mode
The default display cycle varies depending on the input video signal and output stream
selection. It shows the selected inputs and their resolutions, stream bit rate, and output
resolution. During recording, the current length of the recording and time remaining are
added to the default cycle.
