SMP300 Series • Web-Based User Interface 61
4. To enable the meters, select the Enable Meter
checkbox below the meters (see figure36).
Left and right channel indicators display the
audio output level (in dBFS) when there is an
active audio output. The boxes at the top of the
meters are red when audio clipping occurs and
black when audio is not clipped.
Figure 36. Audio Output Meter
Start an AdHoc Recording
A user logged on to the SMP, either at the user level or the administrator level, can initiate an
adhoc (unscheduled) recording. To start an adhoc recording from the AV Controls panel,
see the SMP300SeriesEmbedded Web Pages Help File.
NOTES:
• For more information about single and dual storage modes, see Setting the
Default Recording Media on page90) within Configuration > System
Settings.
• If the unit is set for recording destination limiting, users do not have the option to
select a different storage location. The storage location or locations are preselected
and cannot be changed from this dialog box.
• If the recording is restricted to a USB device with multiple partitions, then partition
selection within the USB drive is still available.
• Ad hoc recordings can last up to eight hours. At the end of eight hours, the SMP
stops recording.
Recording Destination Options
If the unit is set for single storage mode (recordings are saved to only one storage drive),
choose a recording destination from the Recording Destination drop-down list (see
figure37).
Figure 37. Ad hoc Recording Destination Dialog, Single Recording Destination
